IPT428XV

4MP HD IR Fixed Eyeball Network Turret Camera

Want to buy this product?
Find A Dealer

Key Features

  • Fully Adheres to National Defense Authorization Act (NDAA) Guidelines
  • High quality image with 4 MP (2560 x 1440), 1/3.0″ CMOS sensor; H.265, H.264, MJPEG
  • Supports ultra motion detection
  • Smart dual-light ensures high quality image
  • Built-in mic
  • Supports 9:16 corridor mode
  • Smart IR, up to 30 m (98.4 ft) IR distance
  • DC12V or PoE (IEEE 802.3af)
  • Built-in Micro-SD Card Slot enables local storage up to 512GB and ANR
  • IP67 Weather Resistant Housing and Optional Mounts Available

Compare
SKU: IPT428XV Categories: ,
Camera
Sensor 1/3.0" CMOS
Minimum illumination Color: 0.001 Lux (F1.6, AGC ON), 0 Lux with light
True Day / Night IR-cut filter with auto switch (ICR)
Smart Illumination Support
Shutter Auto / Manual, 1 ~ 1/100000s
WDR DWDR
S/N >52 dB
Lens
Lens 2.8 mm
Iris F1.6
Field of View (H) 93.2°
Field of View (V) 51.5°
Field of View (D) 108.0°
DORI
DORI Distance

Lens (m)

2.8 mm

Detect (m)

63.0 m (206.7 ft)

Observe (m)

25.2 m (82.7 ft)

Recognize (m)

12.6 m (41.3 ft)

Identify (m)

6.3 m (20.7 ft)
Illuminator
IR Range 30 m (98.4 ft.)
Warm Light Range 30 m (98.4 ft.)
Wavelength 850 nm
Supplemental Light Dual Light
Video
Video Compression H.265, H.264, MJPEG
Frame Rate 4 MP (2560 × 1440), max. 25 fps (Main Stream)
3 MP (2304 × 1296), max. 30 fps (Main Stream)
1080P (1920 × 1080), max. 30 fps (Main Stream)
D1 (720 × 576), max. 30 fps (Sub Stream)
640 × 360, max. 30 fps (Sub Stream)
2CIF (704 × 288), max. 30 fps (Sub Stream)
CIF (352 × 288), max. 30 fps (Sub Stream)
Video Bit Rate 128 Kbps~ 16 Mbps
ROI Support
OSD Up to 4 OSDs
Privacy Mask Up to 4 areas
Video Stream Dual streams
White Balance Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2 / Area white balance
Digital Noise Reduction 2D / 3D DNR
Flip Normal / Vertical / Horizontal / 180°
HLC Support
BLC Support
Defog Digital Defog
Dewarping N/A
Events
Basic Detection Ultra motion detection, Motion detection, Audio detection, Tampering alarm
Smart Detection N/A
General Functions Watermark, IP Address Filtering, Alarm input, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication
Other Functions N/A
Audio
Audio Compression G.711U, G.711A
Audio Bitrate 64 Kbps
Two-way audio N/A
Suppression Support
Sampling Rate 8 kHz
Storage
Edge Storage Micro SD, up to 512GB
Network Storage ANR; NAS (NFS)
Network
Protocols IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP, 802.1x, SNMP, QoS, SSL/TLS, SSH, HTTPS, SMTP
Compatible Integration ONVIF (Profile S, Profile G, Profile T), API, SDK
User/Host Up to 32 users. 3 user levels: administrator, common user and operator
Client Guard Station, Guard Viewer, Guard Live
Web Browser Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+
Pan & Tilt (N/A)
Optical Zoom N/A
Pan N/A
Tilt N/A
Presets N/A
Patrols N/A
Dwell Times N/A
Home Position N/A
Auto Tracking N/A
Interface
Audio I/O N/A
Alarm I/O N/A
Built-In Mic Support
Built-In Speaker N/A
Network 1 x RJ45 10M/100M Base-TX Ethernet
Additional Ports N/A
General
Power DC 12 V±25%, PoE (IEEE 802.3af)
Dimensions Ø117.8 mm × 100.3 mm (Ø4.6" × 3.9") (Ø × H)
Material Graphene + Plastic
Environment Working: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing); Storage: -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Screws & Offset 3- Ø3.8 mm; Ø 80.0 mm
Reset Button Support
Conformity Certifications IP67, CE, UL, FCC
