Camera | |||||
---|---|---|---|---|---|
Sensor | 1/2.7” 5MP, progressive scan CMOS | ||||
Minimum illumination | Color: 0.002 lux (F1.6, AGC ON); 0 lux with IR on | ||||
True Day / Night | IR-cut filter with auto switch (ICR) | ||||
Shutter | Auto / Manual, 1 ~ 1/100000s | ||||
Adjustment angle (3-way Axis) | Pan: 0° ~ 360°; Tilt: 0° ~ 90°; Rotate: 0° ~ 360° | ||||
WDR | 130dB | ||||
S/N | >56dB | ||||
Lens | |||||
Lens | 2.8mm @ F1.6 | ||||
Iris | Fixed | ||||
Field of View (H) | 110.71° | ||||
Field of View (V) | 56.39° | ||||
Field of View (D) | 114.11° | ||||
DORI | |||||
DORI Distance |
| ||||
Illuminator | |||||
IR Range | Up to 80m (262ft) IR range | ||||
Wavelength | 850nm | ||||
IR On/Off Control | Auto/Manual | ||||
Video | |||||
Video Compression | Ultra 265, H.265, H.264, MJPEG | ||||
H.264 code profile | Baseline profile, Main profile, High profile | ||||
Frame Rate | Main Stream: 5MP (2880 x 1620), Max 30fps; 4MP (2560 x 1440), Max 30fps; 3MP (2304 x 1296), Max 30fps; 1080P (1920 x 1080) Sub Stream: 1080P (1920 x 1080), Max 30fps; 720P (1280 x 720) Max 30fps; D1 (720 x 576), Max 30fps; 640 x 360, Max 30fps; 2CIF (704 x 288), Max 30fps; CIF (352 x 288), Max 30fps Third Stream: D1 (720 x 576), Max 30fps; 640 x 360, Max 30fps; 2CIF (704 x 288), Max 30fps; CIF (352 x 288), Max 30fps | ||||
Video Bit Rate | 128 Kbps~16 Mbps | ||||
U-code | Support | ||||
OSD | Up to 8 OSDs | ||||
Privacy Mask | Up to 4 areas | ||||
ROI | Up to 8 areas | ||||
Video Stream | Triple | ||||
Image | |||||
White Balance | Auto / Outdoor / Fine Tune / Sodium Lamp / Locked / Auto2 | ||||
Digital Noise Reduction | 2D / 3D DNR | ||||
Smart IR | Support | ||||
Flip | Normal / Vertical / Horizontal / 180° / 90°Clockwise / 90°Anti-clockwise (Corridor) | ||||
HLC | Supported | ||||
BLC | Supported | ||||
Defog | Digital Defog | ||||
Auto Scene Match (ASM) | Support (Only WDR) | ||||
Intelligent Analytics | |||||
Smart intrusion prevention | Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection | ||||
Recognition | Face capture | ||||
Attribute Collection | Color retrieval | ||||
People Counting | Support people flow counting and crowd density monitoring | ||||
Statistical Analysis | People counting, support people flow counting and crowd density monitoring | ||||
Intrusion Events | |||||
Basic Detection | Motion detection, Ultra motion detection, tampering alarm, audio detection | ||||
General Function | Watermark, IP address filtering, tampering alarm, alarm input, alarm output, access policy, ARP protection, RTSP authentication, user authentication | ||||
Audio | |||||
Audio Compression | G.711U, G.711A | ||||
Audio Bitrate | 64 Kbps | ||||
Two-way audio | Support | ||||
Suppressione | Support | ||||
Sampling Rate | 8KHZ | ||||
Storage | |||||
Edge Storage | Micro SD, up to 128GB | ||||
Network Storage | ANR | ||||
Network | |||||
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL/TLS, SNMP, SSH | ||||
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API | ||||
User/Host | Up to 32 users. 2 user levels: administrator and common user | ||||
Security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF | ||||
Client | Guard Station, Guard Viewer | ||||
Web Browser | Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above; Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above | ||||
Interface | |||||
Audio I/O | Input: impedance 35kΩ; amplitude 2V [p-p]; Output: impedance 600Ω; amplitude 2V [p-p] | ||||
Alarm I/O | 1 / 1 | ||||
Built-in Mic | Support | ||||
Network | 1 * RJ45 10M/100M Base-TX Ethernet | ||||
General | |||||
Power | DC 12V±25%, PoE (IEEE 802.3af); Power consumption: Max 10W | ||||
Power Interface | Ø 5.5mm coaxial power plug | ||||
Dimensions (Ø × H) | 269 x 96 x 82mm (10.6” x 3.8 x 3.2”) | ||||
Weight | 0.84kg (1.85lb) | ||||
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) | ||||
Surge Protection | 4KV | ||||
Conformity Certifications | IP67, CE, FCC |
